Turbine Flowmeter
Turbine Flowmeter
YGWL
Features
- They are of high-accuracy
- RS-485Easy to install and maintain modbus communicaon, 4- 20mA output
- Can handle a wide range of flow rates, from low to high velocities.
- Can provide both digital and analog output signals.
- Can be constructed from various materials, such as stainless steel, brass, or plastic, to accommodate different fluid types
A type of speed instrument, the series liquid turbine flowmeter offers the following benefits: minimal pressure loss, easy maintenance, high accuracy, strong repeatability, and a straightforward construction. It is employed to calculate the low viscosity liquid volume flow in a closed conduit. in the paper, water supply, metallurgy, petroleum, and other sectors with a variety of uses.
Principle of Turbine flowmeter flange connection
The flow meter sensor’s internal impeller rotates as the measured liquid passes through it, assisted by the liquid’s kinetic energy. Currently, the detecting device’s magnetic resistance fluctuates on a regular basis due to the impeller blade. Consequently, at both ends of the detecting coil, an electric pulse signal proportionate to the flow rate is generated. This signal is then amplified by the preamplifier and supplied to the display unit. The display unit’s single chip microcomputer system computes based on the number of pulses recorded and the flowmeter’s meter coefficient K. It then shows the instantaneous flow rate as well as the total quantity accumulated.
